Specifications
| Customization | Available |
|---|
| Screen Size | 19 Inch |
|---|
| Aspect Ratio | 5:4 |
|---|
| Model NO. | CJ190W5BZ |
|---|
| Application | Security Monitoring System |
|---|
| Screen Type | Resistive |
|---|
| Resistive Touch Screen Type | Digital |
|---|
| Customized | Support Custom |
|---|
| Regular Size | 5inch~24inch |
|---|
| Controller | Eeti/Ilitek USB & RS232 |
|---|
| Touch Points | 1/2 Points Touch |
|---|
| Warranty | 3 Years |
|---|
| Usage | Monitor, TV, Advertising, Signage, Kiosk |
|---|
| Lift Time | >30, 000, 000 Points |
|---|
| Structure | Glass + Film |
|---|
| Function | Anti Oil, Anti Shock, Anti Sun, Anti Scra |
|---|
| OS | Windows7/8/10/XP/Android/Linux/iMac/Raspberry Pi |
|---|
| Certification | CE/FCC/RoHS/ISO9001/ISO14001 |
|---|
| Transport Package | 1/10/20PCS/Cartons |
|---|
| Trademark | CJTOUCH/THINKTOUCH |
|---|
| Origin | China |
|---|
| HS Code | 8471609000 |
|---|
| Production Capacity | 40000pieces/Month |
|---|
| Package Size | 45.00cm * 39.00cm * 13.00cm |
|---|
| Package Gross Weight | 6.000kg |
|---|
| Operation | -10°C ~ +60°C ; Storage : -40°C ~ +80°C |
|---|
| Storage | 10%RH ~ 90%RH, no condensing |
|---|
| Heat Cycle | 70°C /240 hrs ; |
|---|
| Cold Cycle | -40°C /240 hrs ; |
|---|
| Thermal Cycle | -40°C ~7°0C [60 min./cycle] *10 cycles |
|---|
| Delivery time | Standard Dustproof Sample order 1-2 Days,Vandal proof/Anti-Glare type 2-4 Days. |
|---|
| Main Product | Touch Screen, Touch Foil, LCD/LED Monitor, Touch PC, Kiosk and Accessories etc. |
|---|
| Category | Phones, Tablets & Displays |
|---|
| Manufacturer | Dongguan Cjtouch Electronic Co., Ltd. |
|---|
Detailed parameters
| Mechanical | Dong Guan CJTouch Electronic Co.,Ltd--CJTOUCH--Made in China Factory TouchScreen,Touch Panel,LCD Monitors,Touch All in one onc PC Computer,Kiosk,Monitor,TV,Advertising,Signage,Kiosk,Self Service etc |
|---|
| Regular Size | 5 inch To 22 inch |
|---|
| Input Method | Finger or gloved hand (rubber ,cloth or leather) |
|---|
| Active Force | Stylus or Finger or Similar <45g~110g |
|---|
| Ball Impact | ø13.0. Steel Ball/9g, Height=30cm, 1 time, no damage [Impact at center area] |
|---|
| Durability | >30,000,000 touches |
|---|
| PositionAccuracy | <1.5% Positional Accuracy |
|---|
| Light Transmit | 0.82 |
|---|
| Clear surface | <3% |
|---|
| Anti-Glare Surface | <4% |
|---|
| Anti-Newton | <10% |
|---|
| Gloss | 90±20 gloss units tested on a hard-coated front surface ,Accordance with ASTM D 2457 |
|---|
| Supply voltage | DC5V |
|---|
| Circuit Resistance | X:20~25Ω0, Y:20~250Ω |
|---|
| Linearity | X<1.5%, Y<1.5% |
|---|
| Response | <15ms |
|---|
| Insulation | >20MΩ/25V(DC) |
|---|
| Endurance | No acting damage at DC50V/60sec |
|---|
| Resolution | 4096 x 4096 |
|---|
| Temperature | Operation : -10°C ~ +60°C ; Storage : -40°C ~ +80°C |
|---|
| Humidity | Operation : 20%RH ~ 85%RH, no condensing ; Storage : 10%RH ~ 90%RH, no condensing |
|---|
| Waterproof | Not damaged by running water applied to the active area |
|---|
| Cycle | Heat Cycle : 70°C /240 hrs ; Cold Cycle : -40°C /240 hrs ; Thermal Cycle : -40°C ~7°0C [60 min./cycle] *10 cycles |
|---|
| OS | Windows7/8/10/XP,Andorid,Linux,Imac,Raspberry pi etc |
|---|
| Warranty | Free for 1 Years |
|---|
Description
Cheaper Touch Screen 19 Inch 5 Wire Resistive Touch Panel Interactive Flat Panel Vending Machine Kiosk Screen Overlay Glass Kit Touchscreen is listed in phones, tablets & displays (More Accessories).
Key details
- Application: Security Monitoring System
- Screen Size: 19 Inch
- Certification: CE/FCC/RoHS/ISO9001/ISO14001
- Warranty: 3 Years
- Aspect Ratio: 5:4
- Screen Type: Resistive
- Resistive Touch Screen Type: Digital
- Customized: Support Custom
The supplier lists this product. Its stated application is Security Monitoring System. The listed model is CJ190W5BZ. Supplier-stated function: Anti Oil, Anti Shock, Anti Sun, Anti Scra. The specifications reflect the information publicly displayed on the listing. Screen Size: 19 Inch. Model NO.: CJ190W5BZ. Regular Size: 5inch~24inch. Production Capacity: 40000pieces/Month. Package Size: 45.00cm * 39.00cm * 13.00cm. Package Gross Weight: 6.000kg.
Ordering through ToyBox UAE
Minimum order is 1 piece at US$30.00 – 33.00 per piece. Send one inquiry and ToyBox UAE confirms compatibility with your device, price, lead time and shipping with the factory, inspects the goods and delivers them to you in the UAE or abroad.
Request a quote for this product
