Specifications
| Model NO. | CTB104C-4F-AL |
|---|
| Application | Personal Communication System |
|---|
| Screen Type | Surface Acoustic Wave |
|---|
| Resistive Touch Screen Type | Digital |
|---|
| Customized | Custom Made Ok |
|---|
| Regular Size | 7inch~32inch |
|---|
| Resolution | 4096*4096 |
|---|
| Touch Points | 1/2 Points Touch |
|---|
| Voltage | 5V /12V |
|---|
| Warranty | 3 Years |
|---|
| Drive | Free Drive, Elo/3m/Generaltouch etc Compatible |
|---|
| Outframe | Non-Frame/Aluminum/Plastic Option |
|---|
| Usage | Vandalproof/Waterproof/Anti-Glare/Tempered Glass |
|---|
| OS | Windows7/8/10/XP/Android/Linux/iMac/Raspberry Pi |
|---|
| Certification | Ce/FCC/RoHS/ISO9001/ISO14001 |
|---|
| Transport Package | 1/10/20PCS/Cartons |
|---|
| Trademark | CJTOUCH/THINKTOUCH |
|---|
| Origin | China |
|---|
| HS Code | 8471609000 |
|---|
| Production Capacity | 40000pieces/Month |
|---|
| Package Size | 45.00cm * 34.00cm * 23.00cm |
|---|
| Package Gross Weight | 2.000kg |
|---|
| Customization | Available |
|---|
| Screen Size | 10.4 Inch |
|---|
| Aspect Ratio | 16:9 |
|---|
| Shipping Cost | Freight and delivery time are quoted with your inquiry. |
|---|
| Parts | Double-Side Adhensive /SAW TouchScreen Controller /USB-RS232 Cable /Dustproof Strip. |
|---|
| Operating Tempt. | -10°C to +60°C ; Storage Tempt. : -20°C to +70°C |
|---|
| Delivery time | Standard Dustproof Sample order 1-2 Days,Vandal proof/Anti-Glare type 2-4 Days. |
|---|
| Main Product | Touch Screen, Touch Foil, LCD/LED Monitor, Touch PC, Kiosk and Accessories etc. |
|---|
| Category | Phones, Tablets & Displays |
|---|
| Manufacturer | Dongguan Cjtouch Electronic Co., Ltd. |
|---|
Detailed parameters
| Technology | Surface Acoustic Wave/ SAW TouchScreen Panel Glass |
|---|
| Sizes | 7''-32" (SAW TouchScreen) |
|---|
| Resolution | 4096 x 4096 ,Z-axis 256 |
|---|
| Touch Glass | 3/4/6mm Pure Transparent Electronic TouchScreen Panel Glass (IP65 IP66 Tempered/ Vandalproof/ Anti-Glare/ Waterprof option) |
|---|
| Voltage | 5V /12V Option |
|---|
| Interface | USB / RS232 |
|---|
| Drive/Controller | Free Drive,Plug and Play, ELO/ 3M/ GeneralTouch/ KeeTouch/ OneTouch/ ETWO etc Compatible |
|---|
| Operation System | Windows7/8/10/XP/ Android/ Linux/ Imac/ Raspberry pi etc |
|---|
| Transducer Position | Glass bevel angle, up surface 0.5mm |
|---|
| Outframe | Vandalproof Aluminum / Waterproof Plastic Outframe Option |
|---|
| Accuracy | < 2mm |
|---|
| Light Transmission | >92% /ASTM |
|---|
| Touch Force | 30g |
|---|
| Durability | Scratch-free; > 50,000,000 touches in one location without failure. |
|---|
| Surface Hardness | Mohs' 7 |
|---|
| Multi-touch | 1/2 Points Optional , software support |
|---|
| Temperature | Operating Tempt. : -10°C to +60°C ; Storage Tempt. : -20°C to +70°C |
|---|
| Humidity | 10%-90% RH / 40°C |
|---|
| Altitude | 3800m |
|---|
| Accessories | TouchScreen,USB RS232 Cables,TouchScreen Panel Controller Board,Double-sided Adhesive, Dustproof Strip etc |
|---|
| Certificates | CE, FCC, RoHS,ISO9001,ISO14001 |
|---|
| Projected CapacitiveTouch Screen | IR Infrared Touch Panel Screen | SAW TouchScreen Panel |
|---|
| 4/5 Wire Resistive Touch Panels | PCAP Nano Touch Foil Touch Film | Resistive Touch Foil/Privacy Film |
|---|
| SAW Touch Monitors | ELO/3M Compatible Touch Monitors | P-cap Touch Monitor Display |
|---|
| IR Infrared Touch Display | Resistive Touch Display Monitor | Hight Brightness Monitors |
|---|
| Wall Mounted Touch Monitors | Desktop Touch Monitor | Industrial Monitors |
|---|
| Indoor Vandalproof Monitors | Outdoor Waterproof Anti Sun Monitor | Custom made Touch Monitors |
|---|
| Openframe/Embedded Touch PC | Wall mounted All in one Touch Computer | Desktop TouchScreen PC |
|---|
| Interactive Multimedial Kiosk | Self Service Terminal |
|---|
| Advertising Signage Displayer | Information/Queuing/Ticket/Ordering Equipment | Vending Machine |
|---|
| Touch All in one Computer PC | ATM,Payment or Bank Device | Touch Table,Touch TV |
|---|
| Electronic Education Whiteboard | Indoor/Outoor/Industrial/Commercial/Custom | AI/Intelligence Robot kiosk |
|---|
Description
Cjtouch LCD Screen 10.4 Inch Saw Touch Panel Touchscreen for Open Monitor USB RS232 Interface is listed in phones, tablets & displays (More Accessories).
Key details
- Application: Personal Communication System
- Voltage: 5V /12V
- Screen Size: 10.4 Inch
- Certification: Ce/FCC/RoHS/ISO9001/ISO14001
- Warranty: 3 Years
- Screen Type: Surface Acoustic Wave
- Resistive Touch Screen Type: Digital
- Customized: Custom Made Ok
The supplier lists this product. Its stated application is Personal Communication System. The listed model is CTB104C-4F-AL. The specifications reflect the information publicly displayed on the listing. Model NO.: CTB104C-4F-AL. Regular Size: 7inch~32inch. Voltage: 5V /12V. Production Capacity: 40000pieces/Month. Package Size: 45.00cm * 34.00cm * 23.00cm. Package Gross Weight: 2.000kg. Screen Size: 10.4 Inch.
Ordering through ToyBox UAE
Minimum order is 1 piece at US$28.00 – 30.00 per piece. Send one inquiry and ToyBox UAE confirms compatibility with your device, price, lead time and shipping with the factory, inspects the goods and delivers them to you in the UAE or abroad.
Request a quote for this product
