Specifications
| Customization | Available |
|---|
| Noise | ≥105dB |
|---|
| Hi-Fi | Hi-Fi |
|---|
| Model NO. | MA-206 |
|---|
| Activity | Passive |
|---|
| Operation Mode | Button Control |
|---|
| Speaker System | Optional Combination |
|---|
| Speaker Material | Metal |
|---|
| Application | Commercial, Home |
|---|
| Certification | CCC |
|---|
| Monitor | LCD Screen |
|---|
| THD | >0.01% |
|---|
| Operating Temperature | -10 °C to +60 °C |
|---|
| PC Interfaces | Rj-45, USB, RS-485 |
|---|
| Channel Crosstalk | < -100 Db @ 1 kHz |
|---|
| Power | AC 220 V - 50 Hz |
|---|
| Transport Package | Carton |
|---|
| Specification | 482 × 44.5 × 265 mm |
|---|
| Trademark | Lightning Cloud |
|---|
| Origin | China |
|---|
| Package Size | 50.00cm * 50.00cm * 30.00cm |
|---|
| Package Gross Weight | 3.500kg |
|---|
| Lead Time | 7 days (1 - 1 set) To be negotiated ( > 1 set) |
|---|
| Built-in generator | sine, pink & white noise. |
|---|
| DSP chip | 32-bit fixed/floating-point |
|---|
| Audio latency | < 2 ms |
|---|
| D/A conversion | 24-bit |
|---|
| Sampling rate | 96 kHz |
|---|
| Inputs | 2 / 3 / 4-channel options |
|---|
| Audio connector | XLR |
|---|
| Input impedance | 10 kΩ |
|---|
| Max input level | +14 dBu |
|---|
| Input delay | 0 – 500 ms per channel |
|---|
| Functions per channel | noise gate, compressor, HP/LP filters, 7-band PEQ |
|---|
| Signal generator | sine, pink, white noise |
|---|
| Outputs | 4 / 6 / 8-channel options |
|---|
| Output impedance | 100 Ω |
|---|
| Max output level | +14 dBu |
|---|
| Output delay | 0 – 500 ms per channel |
|---|
| Frequency response | 20 Hz – 20 kHz ±1 dB |
|---|
| THD+N | < 0.003 % @ 1 kHz |
|---|
| SNR | 112 dB (A-wt), 110 dB (un-wt) |
|---|
| Noise floor | < –93 dB |
|---|
| Display | 1.77-inch IPS color screen |
|---|
| Indicators | signal present, output mute, clip |
|---|
| Dimensions (W×H×D) | 482 × 44.5 × 265 mm |
|---|
| Weight | 3.5 kg |
|---|
| Core Advantage | Dual-Ecosystem-Driven Supply Chain Matrix |
|---|
| Strategic Ecosystem I | Core Partner in Global Smart Audio Systems |
|---|
| Strategic Ecosystem II | Strategic Manufacturer in Smart Interactive Display |
|---|
| Lightning Cloud Value | Integrated Solution Delivery Capability |
|---|
| Category | Flash Drives & Memory Cards |
|---|
| Manufacturer | Shandong Lightning Cloud Technology Engineering Co., Ltd. |
|---|
Detailed parameters
| 1 | DSP chip: 32-bit fixed/floating-point |
|---|
| 2 | Audio latency: < 2 ms |
|---|
| 3 | D/A conversion: 24-bit |
|---|
| 4 | Sampling rate: 96 kHz |
|---|
| 5 | Inputs: 2 / 3 / 4-channel options |
|---|
| 6 | Audio connector: XLR |
|---|
| 7 | Input impedance: 10 kΩ |
|---|
| 8 | Max input level: +14 dBu |
|---|
| 9 | Input delay: 0 – 500 ms per channel |
|---|
| 10 | Functions per channel: noise gate, compressor, HP/LP filters, 7-band PEQ |
|---|
| 11 | Signal generator: sine, pink, white noise |
|---|
| 12 | Outputs: 4 / 6 / 8-channel options |
|---|
| 13 | Output impedance: 100 Ω |
|---|
| 14 | Max output level: +14 dBu |
|---|
| 15 | Output delay: 0 – 500 ms per channel |
|---|
| 16 | Frequency response: 20 Hz – 20 kHz ±1 dB |
|---|
| 17 | THD+N: < 0.003 % @ 1 kHz |
|---|
| 18 | SNR: 112 dB (A-wt), 110 dB (un-wt) |
|---|
| 19 | Noise floor: < –93 dB |
|---|
| 20 | Channel crosstalk: < –100 dB @ 1 kHz |
|---|
| 21 | PC interfaces: RJ-45, USB, RS-485 |
|---|
| 22 | Display: 1.77-inch IPS color screen |
|---|
| 23 | Indicators: signal present, output mute, clip |
|---|
| 24 | Power: AC 220 V – 50 Hz |
|---|
| 25 | Dimensions (W×H×D): 482 × 44.5 × 265 mm |
|---|
| 26 | Weight: 3.5 kg |
|---|
| 27 | Operating temperature: –10 °C to +60 °C |
|---|
Description
Network Remote Control 2X6 Channel Professional 1u Rackmount Digital Audio Processor is listed in flash drives & memory cards (Storage, Network & Smart Home).
Key details
- Application: Commercial, Home
- Certification: CCC
- Noise: ≥105dB
- Hi-Fi: Hi-Fi
- Activity: Passive
- Operation Mode: Button Control
- Speaker System: Optional Combination
- Speaker Material: Metal
The supplier lists this product. Its stated application is Commercial, Home. The listed model is MA-206. The specifications reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: MA-206. Speaker Material: Metal. Power: AC 220 V – 50 Hz. Audio connector: XLR. Input impedance: 10 kΩ. Output impedance: 100 Ω. Frequency response: 20 Hz – 20 kHz ±1 dB. Noise floor: < –93 dB.
Ordering through ToyBox UAE
Minimum order is 1 set at US$475.71 per set. Send one inquiry and ToyBox UAE confirms compatibility with your device, price, lead time and shipping with the factory, inspects the goods and delivers them to you in the UAE or abroad.
