Specifications
| Model NO. | CIP600AP-K1-DNA2 |
|---|
| Application | Education and Training System |
|---|
| Screen Type | Infrared |
|---|
| Resistive Touch Screen Type | Infrared IR Touch Panel |
|---|
| Customized | Support Custom |
|---|
| Regular Size | 10inch~300inch |
|---|
| Interface | USB, RS232, Elo/3m Compatible |
|---|
| Touch Points | 1/2/4/6/10/16 Points Touch |
|---|
| Warranty | 3 Years |
|---|
| Usage | LCD Monitor, TV, Ads, Signage, Kiosk, Self Service |
|---|
| Drive | Free Drive, Plug and Play, Elo/3m Compatible |
|---|
| Characters | Vandalproof/Waterproof/Anti-Glare |
|---|
| OS | Windows7/8/10/XP/Android/Linux/iMac/Raspberry Pi |
|---|
| Certification | CE/FCC/RoHS/ISO9001/ISO14001 |
|---|
| Transport Package | 1/10/20PCS/Cartons |
|---|
| Trademark | CJTOUCH/THINKTOUCH |
|---|
| Origin | China |
|---|
| HS Code | 8471609000 |
|---|
| Production Capacity | 40000pieces/Month |
|---|
| Package Size | 100.00cm * 17.00cm * 35.00cm |
|---|
| Package Gross Weight | 4.000kg |
|---|
| Customization | Available |
|---|
| Screen Size | 59.6 Inch |
|---|
| Aspect Ratio | 16:9 |
|---|
| Shipping Cost | Freight and delivery time are quoted with your inquiry. |
|---|
| CIN(10.1-42inch) | 3mm Vandalproof Tempered TouchScreen Glass; |
|---|
| CIP(32-86inch) | without glass. |
|---|
| Touch | 6ms |
|---|
| Drawing | 6ms |
|---|
| Anti -Static Discharge (Standard | B) |
|---|
| Delivery time | Standard Dustproof Sample order 1-2 Days,Vandal proof/Anti-Glare type 2-4 Days. |
|---|
| Main Product | Touch Screen, Touch Foil, LCD/LED Monitor, Touch PC, Kiosk and Accessories etc. |
|---|
| Category | Phones, Tablets & Displays |
|---|
| Manufacturer | Dongguan Cjtouch Electronic Co., Ltd. |
|---|
Detailed parameters
| P/N | CIP Slim series |
|---|
| Overlay Thickness | 14.6 mm |
|---|
| Overlay Frame Width | 19.1 mm |
|---|
| Housing | Aluminum frame/ Plastic frame |
|---|
| Input Method | Finger or touch pen |
|---|
| Touch Points | NA2= 2 Touch Points,NA4= 4 Touch Points, NA6=6 Touch Points |
|---|
| Touch Activation Force | Non Minimum activation force |
|---|
| Position Accuracy | 1mm |
|---|
| Resolution | 4096(W)×4096(D) |
|---|
| Response Time | Touch: 6ms |
|---|
| Cursor Speed | 120 dot/sec |
|---|
| Glass | 4mm glass Transparency : 92% |
|---|
| Object Touch Size | ≥ Ø5mm |
|---|
| Touch Intensity | Over 60 millions single touch |
|---|
| Operating Voltage | DC 4.5V ~ DC 5.5V |
|---|
| Power | 1.0W (100mA at DC 5V) |
|---|
| Anti -Static Discharge (Standard :B) | Touch Discharge,Grade 2:Lab Vol 4KV |
|---|
| Temperature | operating:-10 °C ~ 60 °C |
|---|
| Humidity | operating:20% ~85% |
|---|
| Relative Humidity | 40 °C,90% RH |
|---|
| Anti - glare Test | Incandescent lamp (220V,100W) , |
|---|
| Altitude | 3,000m |
|---|
| Interface | USB2.0 full speed |
|---|
| Seal Ability | IP64 Anti-Spill (Customizable to IP65 Waterproof) |
|---|
| Working Environment | Directly Under sunlight ,indoor and outdoor |
|---|
| Application of Display | Touch Screen Monitor/Touch Display/Touch LCD/ Touch Kiosks |
|---|
| Operate system | Windows 7,Windows 8,Windows 10, Andriod,Linux |
|---|
| Calibration tool | Precalibrated & Software can be download in CJTouch Website |
|---|
| VID | 1FF7 |
|---|
| PID | 0 013 |
|---|
Description
Digital Photo Touchscreen 60 Inch IR Touch Frame LCD Screen USB Waterproof Overlay Kiosk Screen Serlf Service Touch Panel is listed in phones, tablets & displays (More Accessories).
Key details
- Interface: USB, RS232, Elo/3m Compatible
- Application: Education and Training System
- Screen Size: 59.6 Inch
- Certification: CE/FCC/RoHS/ISO9001/ISO14001
- Warranty: 3 Years
- Screen Type: Infrared
- Resistive Touch Screen Type: Infrared IR Touch Panel
- Customized: Support Custom
The supplier lists this product. Its stated application is Education and Training System. The listed model is CIP600AP-K1-DNA2. The specifications reflect the information publicly displayed on the listing. Model NO.: CIP600AP-K1-DNA2. Regular Size: 10inch~300inch. Production Capacity: 40000pieces/Month. Package Size: 100.00cm * 17.00cm * 35.00cm. Package Gross Weight: 4.000kg. Screen Size: 59.6 Inch.
Ordering through ToyBox UAE
Minimum order is 1 piece at US$62.00 – 75.00 per piece. Send one inquiry and ToyBox UAE confirms compatibility with your device, price, lead time and shipping with the factory, inspects the goods and delivers them to you in the UAE or abroad.
