Specifications
| Customization | Available |
|---|
| Application | Multimedia, DVD Player, Speaker, Computer, Monitor, Telephone, iPod, Microphone, Game Player |
|---|
| Color | Red |
|---|
| Model NO. | dx-mic-22 |
|---|
| Type | Twisted Pair |
|---|
| Species | Microphone Cable |
|---|
| Connector | None |
|---|
| Material Shape | Round Wire |
|---|
| Wire Core Material | Bare Copper Wire |
|---|
| Certification | RoHS, CE, ISO9001 |
|---|
| Brand | Dx |
|---|
| Transport Package | 100m/Plastic Reel |
|---|
| Specification | DX-01 |
|---|
| Trademark | DX |
|---|
| Origin | Jiaxing |
|---|
| HS Code | 85444911 |
|---|
| Production Capacity | 50000 Kilometer/Year |
|---|
| Package Size | 20.00cm * 20.00cm * 10.00cm |
|---|
| Package Gross Weight | 2.000kg |
|---|
| Packing length | 40m/roll ,60m/roll ,91.4m/roll 100m/roll , 200m/roll , 300m/roll ; 305m/roll |
|---|
| Inner packing | plastic cover / wooden drum / paper drum ; |
|---|
| Outer packing | 2/4/ 6 roll / carton box ; |
|---|
| Category | Audio, HDMI & Video Cables |
|---|
| Manufacturer | JIAXING DINGXIN ELECTRON CO., LTD |
|---|
Detailed parameters
| CONDUCTOR | INSULATION O.D(mm) | COTTON YARN | AL FOIL | BRAID/WRAP SHIELD | MON O.D (mm) |
|---|
| 1CX18/0.12 | 1.3 | filled | / | 32/48/64/80/0.12mm | 5.0 |
|---|
| 1CX30/0.12 | 1.8 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 5.8 |
|---|
| 1CX28/0.15 | 2.1 | filed | 10*0.04 | 32/48/64/80/96/0.12mm | 6.0 |
|---|
| 1CX28/0.12 | 2.1 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 6.0 |
|---|
| 2CX10/0.12 | 1.3 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 5.0 |
|---|
| 2CX23/0.12 | 1.5 | filled | 10*0.04 | 32/48/64/80/96/112/0.12mm | 6.0 |
|---|
| 2CX32/0.10 | 1.5 | filled | 10*0.04 | 32/48/64/80/96/112/0.12mm | 6.5 |
|---|
| 2CX21/0.12 | 1.6 | filled | 10*0.04 | 32/48/64/80/96/112/0.12mm | 6.5 |
|---|
| 2CX18/0.12 | 1.3 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 6.0 |
|---|
| 2CX20/0.12 | 1.6 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 5.3 |
|---|
| 2CX10/0.12 | 1.3 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 6.0 |
|---|
| 3CX18/0.12 | 1.3 | filled | 10*0.04 | 32/48/64/80/96/0.12mm | 6.0 |
|---|
| No. of core | Conductor construction | Braid | Max. diameter of cable |
|---|
| AWG | construction No./mm | mm |
|---|
| 1 | 26 | 10/0.12 | 32/0.12 48/0.12 64/0.12 or to client's require | 5.8 |
|---|
| 24 | 19/0.12 | 5.8 |
|---|
| 22 | 26/0.12 | 5.8 |
|---|
| 20 | 42/0.12 | 5.8 |
|---|
| 2 | 26 | 10/0.12 | 6.0 |
|---|
| 24 | 19/0.12 | 6.0 |
|---|
| 22 | 26/0.12 | 6.0 |
|---|
| 20 | 42/0.12 | 6.0 |
|---|
| 3 | 26 | 10/0.12 | 6.0 |
|---|
Description
2 Core 22AWG 0.3mm Mic Cable Audio Wire Flexible Low Noise Tinned Plated Copper Microphone Cable is listed in audio, hdmi & video cables (Cables, Hubs & Adapters).
Key details
- Type: Twisted Pair
- Color: Red
- Certification: RoHS, CE, ISO9001
- Species: Microphone Cable
- Connector: None
- Material Shape: Round Wire
- Wire Core Material: Bare Copper Wire
- Brand: Dx
The supplier lists this product as Twisted Pair. Its stated application is Multimedia, DVD Player, Speaker, Computer, Monitor, Telephone, iPod, Microphone, Game Player. The listed model is dx-mic-22. The specifications reflect the information publicly displayed on the listing. Model NO.: dx-mic-22. Material Shape: Round Wire. Wire Core Material: Bare Copper Wire. Production Capacity: 50000 Kilometer/Year. Package Size: 20.00cm * 20.00cm * 10.00cm. Package Gross Weight: 2.000kg. Packing length : 40m/roll ,60m/roll ,91.4m/roll 100m/roll , 200m/roll , 300m/roll ; 305m/roll.
Ordering through ToyBox UAE
Minimum order is 10,000 meters at US$0.50 – 1.00 per meter. Send one inquiry and ToyBox UAE confirms compatibility with your device, price, lead time and shipping with the factory, inspects the goods and delivers them to you in the UAE or abroad.
Request a quote for this product
